Keysight B2900 系列精密型源表模块价格实惠，性能出色，并且简单易用。 这些紧凑型台式源表模块可以帮助您快速进行各种高分辨率和高准确度的 I-V（电流与电压）测量。 在使用简便的彩色 LCD 图形界面上轻松查看结果，无需更改连接。
使用单个源表模块即可执行准确的电流和电压测量
无需编程即可使用计算机进行远程测量
在前面板上显示 I-V 曲线和其他类型的图形
享受出色的六位半源表分辨率
电源输出和测量分辨率可达 10 fA 和 100 nV
可以提高测试效率，同时降低拥有成本
Keysight B2900 系列源表模块可以为远程控制仪器提供多种软件应用解决方案，包括：
EasyEXPERT group+ 器件表征软件：直观的 GUI 界面让您可以更简单地完成常见的表征任务，例如测试设置和执行、数据分析和数据管理。
PW9251A PathWave IV 曲线软件：无需编程，即可执行 I-V 测量，并在表格和图形中显示测量数据。
BenchVue 软件：整合多种是德科技仪器的功能，直接通过您的计算机将 B2900 SMU 作为电压源/电流源进行控制。
210 V，3 A（直流）
10.5 A 脉冲
2
10 fA/100 nV
LAN、USB 和 GPIB
100,000 读数/秒
B2901C 精密源/测量单元（SMU）是一款单通道、紧凑且经济高效的台式顶置单元，能够获取并测量电压和电流。
The Keysight B2901C precision source/measure unit (SMU) is a compact, cost-effective 1-channel SMU that accurately sources and measures voltage and current. It offers user-friendly I/V measurements without needing multiple instruments with its 4-quadrant capabilities. The B2901C features a 4.3-inch color display for graphical or numerical measurements and includes PC control software for remote operation at no extra cost. It also supports SCPI commands for seamless integration with conventional SMU setups, ensuring high throughput for efficient testing.
The B2901C enables you to do the following:
Source with a minimum resolution of 1 pA / 1 μV.
Measure with a minimum resolution of 100 fA / 100 nV.
Output up to 210 V and 3 A DC / 10.5 A pulse.
Generate arbitrary waveforms and digitize at intervals as short as 20 μs.
B2902C 精密光源/测量单元（2 ch，100 fA）
The Keysight B2902C precision source/measure unit (SMU) is a compact, cost-effective 2-channel SMU that accurately sources and measures voltage and current. It offers user-friendly I/V measurements without needing multiple instruments with its 4-quadrant capabilities. The B2902C features a 4.3-inch color display for graphical or numerical measurements and includes PC control software for remote operation at no extra cost. It also supports SCPI commands for seamless integration with conventional SMU setups, ensuring high throughput for efficient testing.
The B2902C enables you to do the following:
Source with a minimum resolution of 1 pA / 1 μV.
Measure with a minimum resolution of 100 fA / 100 nV.
Output up to 210 V and 3 A DC / 10.5 A pulse.
Generate arbitrary waveforms and digitize at intervals as short as 20 μs.
The Keysight B2901CL precision source/measure unit (SMU) is a compact, cost-effective 1-channel SMU that accurately sources and measures voltage and current. It offers user-friendly I/V measurements without needing multiple instruments with its 4-quadrant capabilities. The B2901CL features a 4.3-inch color display for graphical or numerical measurements and includes PC control software for remote operation at no extra cost. It also supports SCPI commands for seamless integration with conventional SMU setups, ensuring high throughput for efficient testing.
The B2901CL enables you to do the following:
Source with a minimum resolution of 10 pA / 1 μV.
Measure with a minimum resolution of 1 pA / 100 nV.
Output up to 21 V and 1.5 A DC.
Generate arbitrary waveforms and digitize at intervals as short as 200 μs.
B2910CL 精密光源/测量单元（1声道，10 fA）
The Keysight B2910CL precision source/measure unit (SMU) is a compact, cost-effective 1-channel SMU that accurately sources and measures voltage and current. It offers user-friendly I/V measurements without needing multiple instruments with its 4-quadrant capabilities. The B2910CL features a 4.3-inch color display for graphical or numerical measurements and includes PC control software for remote operation at no extra cost. It also supports SCPI commands for seamless integration with conventional SMU setups, ensuring high throughput for efficient testing.
The B2910CL enables you to do the following:
Source with a minimum resolution of 100 fA / 1 μV.
Measure with a minimum resolution of 10 fA / 100 nV.
Output up to 210 V and 1.5 A DC.
Generate arbitrary waveforms and digitize at intervals as short as 50 μs.
The Keysight B2911C precision source/measure unit (SMU) is a compact, cost-effective 1-channel SMU that accurately sources and measures voltage and current. It offers user-friendly I/V measurements without needing multiple instruments with its 4-quadrant capabilities. The B2911C features a 4.3-inch color display for graphical or numerical measurements and includes PC control software for remote operation at no extra cost. It also supports SCPI commands for seamless integration with conventional SMU setups, ensuring high throughput for efficient testing.
The B2911C enables you to do the following:
Source with a minimum resolution of 10 fA / 100 nV.
Measure with a minimum resolution of 10 fA / 100 nV.
Output up to 210 V and 3 A DC / 10.5 A pulse.
Generate arbitrary waveforms and digitize at intervals as short as 10 μs.
B2912C 精密光源/测量单元（2 ch，10 fA）
The Keysight B2912C precision source/measure unit (SMU) is a compact, cost-effective 2-channel SMU that accurately sources and measures voltage and current. It offers user-friendly I/V measurements without needing multiple instruments with its 4-quadrant capabilities. The B2912C features a 4.3-inch color display for graphical or numerical measurements and includes PC control software for remote operation at no extra cost. It also supports SCPI commands for seamless integration with conventional SMU setups, ensuring high throughput for efficient testing.
The B2912C enables you to do the following:
Source with a minimum resolution of 10 fA / 100 nV.
Measure with a minimum resolution of 10 fA / 100 nV.
Output up to 210 V and 3 A DC / 10.5 A pulse.
Generate arbitrary waveforms and digitize at intervals as short as 10 μs.
B2911C 精密光源/测量单元（1 ch，10 fA）
The Keysight B2911C precision source/measure unit (SMU) is a compact, cost-effective 1-channel SMU that accurately sources and measures voltage and current. It offers user-friendly I/V measurements without needing multiple instruments with its 4-quadrant capabilities. The B2911C features a 4.3-inch color display for graphical or numerical measurements and includes PC control software for remote operation at no extra cost. It also supports SCPI commands for seamless integration with conventional SMU setups, ensuring high throughput for efficient testing.
The B2911C enables you to do the following:
Source with a minimum resolution of 10 fA / 100 nV.
Measure with a minimum resolution of 10 fA / 100 nV.
Output up to 210 V and 3 A DC / 10.5 A pulse.
Generate arbitrary waveforms and digitize at intervals as short as 10 μs.
B2912C 精密光源/测量单元（2 ch，10 fA）
The Keysight B2912C precision source/measure unit (SMU) is a compact, cost-effective 2-channel SMU that accurately sources and measures voltage and current. It offers user-friendly I/V measurements without needing multiple instruments with its 4-quadrant capabilities. The B2912C features a 4.3-inch color display for graphical or numerical measurements and includes PC control software for remote operation at no extra cost. It also supports SCPI commands for seamless integration with conventional SMU setups, ensuring high throughput for efficient testing.
The B2912C enables you to do the following:
Source with a minimum resolution of 10 fA / 100 nV.
Measure with a minimum resolution of 10 fA / 100 nV.
Output up to 210 V and 3 A DC / 10.5 A pulse.
Generate arbitrary waveforms and digitize at intervals as short as 10 μs.
